550 Watt Power
Delivers continuous 550 watts on your PC providing fully efficient and reliable supply of power.
Single +12V rail to help stability of the PC.
Detailed Specifications.
Dimensions: 150mm x 85mm x 140mm (W x H x D)
Input Voltage: 230 VAC
Input Current: 10A
Input Frequency Vary: 50-60Hz
PFC: Yes – Passive Power Factor Control
Power Excellent Signal: 150-450 ms
Hold Up Time: 1MS-40MS
Efficiency: 75%
MTBF: 100,000 Hours
Protection: OVP / UVP/ OPP
Power: 550W
Operation Temperature: forty five°C
Safety: CE / ROHS
Cooling: 12cm Red Fan
Noise:
General Specifications
Manufacturer Part Number: A-550BR
Has Mains Plug: No
Colour: Black
What’s In The Box: PSU
Unit (Product) Dimensions (mm): 151mm x 141mm x 85mm (W x H x D)
Packaging Dimensions (mm): 217mm x 162mm x 102mm (W x H x D)
Web Weight (KGs): 1.1 KGs
Gross Weight (KGs): 1.2 KGs
Main Features:
Power Factor Keep an eye on (PFC)
Cooling: 12cm Red Fan
New Version 1.3 / 2.03
Silent with better ventilation
ATX 12V compliant for so much CPUs and mainboards
Input Vary : 230Vac, 10A, 50-60Hz
2 x SATA Connectors
3 x Molex Connectors
20+4 Pin Motherboard Connector
Make certain this fits by entering your model number.
550W Switching PSU
20+4 Pin Main Connectors x 1
P4 4-Pin 12V Connectors x 1
4-Pin Molex Peripheral Connectors x 3
SATA Connectors x 2
